- Using the simple electronic box for the easy operation control.
- The uncoiler can choose the hydraulic expansion for infeed device, more efficiency
|
|
 |
Model |
AML - 150
AMLA - 150 |
AML - 200
AMLA - 200 |
AML - 300
AMLA - 300 |
AML - 400
AMLA - 400 |
AML - 500
AMLA - 500 |
AML - 600
AMLA - 600 |
Width of material (mm) |
150 |
200 |
300 |
400 |
500 |
600 |
Thickness of material (mm) |
0.5 ~ 1.6
0.5 ~ 3 |
0.5 ~ 1.6
0.5 ~ 3 |
0.5 ~ 1.6
0.5 ~ 3 |
0.5 ~ 1.6
0.5 ~ 3 |
0.5 ~ 1.6
0.5 ~ 3 |
0.5 ~ 1.6
0.5 ~ 3 |
Coil weight (Kg) |
800 |
800 |
800 |
1500 |
2000 |
2000 |
Uncoil motor (HP) |
1 / 2
1 |
1
1 |
1
2 |
1
2 |
2
2 |
2
3 |
Uncoil O.D. (mm) |
1200 |
1200 |
1200 |
1200 |
1200 |
1200 |
Uncoil I.D. (mm) |
450 ~ 530 |
450 ~ 530 |
450 ~ 530 |
450 ~ 530 |
450 ~ 530 |
450 ~ 530 |
Feed roll (mm) Up |
60 X 2
70 X 1 |
60 X 2
70 X 1 |
60 X 2
70 X 1 |
60 X 2
70 X 1 |
60 X 2
70 X 1 |
60 X 2
70 X 1 |
Feed roll (mm) Lower |
80 X 2
98 X 1 |
80 X 2
98 X 1 |
80 X 2
98 X 1 |
80 X 2
98 X 1 |
80 X 2
98 X 1 |
80 X 2
98 X 1 |
Work roll (mm) |
50 X 7
60 X 7 |
50 X 7
60 X 7 |
50 X 7
60 X 7 |
50 X 7
60 X 7 |
50 X 7
60 X 7 |
50 X 7
60 X 7 |
The main shaft |
70 |
70 |
70 |
90 |
105 |
105 |
Long (mm) |
1600 |
1600 |
1650 |
1750 |
1900 |
1900 |
Width (mm) |
900 |
900 |
1000 |
1100 |
1400 |
1400 |
High (mm) |
1350 |
1350 |
1350 |
1350 |
1350 |
1350 |
|
|
|
 |
- All specifications, dimensions and design are subject to change without prior notice.
|
|
