Model |
ACL - 150 |
ACL - 200 |
ACL - 300 |
Width of material (mm) |
150 |
200 |
300 |
Thickness of material (mm) |
0.5 ~ 1.6 |
0.5 ~ 1.6 |
0.5 ~ 1.6 |
Coil weight (Kg) |
400 |
600 |
800 |
Uncoil motor (HP) |
1 / 2 |
1 |
1 |
|
Model |
ACLA - 150 |
ACLA - 200 |
ACLA - 300 |
Width of material (mm) |
150 |
200 |
300 |
Thickness of material (mm) |
0.5 ~ 3 |
0.5 ~ 3 |
0.5 ~ 3 |
Coil weight (Kg) |
400 |
600 |
800 |
Uncoil motor (HP) |
1 |
1 |
2 |
|
- All specifications, dimensions and design are subject to change without prior notice.
|
 |
|
|
|
